ALSA

For ayone interested in ALSA kernel development...

||| Userspace ALSA

What?
Why?
Configuration files
- Link with alsa-lib
Examples using alsa-lib

What?

Advanced Linux Sound Architecture
Software framework that provides a generic API for sound card device drivers
Replacement for Open Sound System (OSS)

|||

What?

ALSA fixed some shortcomings of OSS at the time
- Simultanous access to sound device was not supported in OSS
- user-space operations
  - Mixing
  - Loopback/snooping
  - Support for non-interleaved interfaces
Main reason was OSS moved to a proprietary license
- Moved back to GPL in 2007
- Kernel: Once you go ALSA, you never go back

|||

What?

Automatic configuration of sound devices
- Through the infamous /usr/share/alsa/cards/*.conf
- Modularized sound drivers
- Thread-safe* design
- User space library (alsa-lib) to simplify programming
  - This is the one we will be using today
- Backwards compatibility layer with OSS

|||

History

Started in 1998
Developed separately from the Linux Kernel
Introduced in v2.5 in 2002
- OSS declared deprecated
Replaced OSS completely in v2.6
- There is however still a compatibility layer in ALSA
- But as you might have guessed, nobody uses it (anymore)
OSS is still being maintained
- Targetting Linux and FreeBSD

|||

Who uses it?

Linux Sound Servers
- PulseAudio
- JACK
PortAudio
- Backbone of Audacity
PipeWire

Why?

Why use ALSA/OSS/sound server over ALSA/OSS/sound server?

|||

Why you should use ALSA over OSS

Only use OSS if you just woke up from a 20 year nap and use kernel v2.4
More support for ALSA/better supported in Linux

|||

Why you should use ALSA over a sound server

Direct/Full control
- Can also be a disadvantage
- You are responsible for xrun recovery
- You are responsible for ALSA quirks
Minimal performance overhead
- Less latency?
  - Not true with JACK
  - But JACK does take more CPU cycles
Mixing built-in through plugins
- dmix, dsnoop, asym
- See https://alsa.opensrc.org/AlsaSharing
- Don't know about the latency impact of this though...

But it's still a lot of hassle

|||

Why you should use a sound server over ALSA

Takes care of all the hassle
Multiple programs accessing same device
Mixing streams
Separate stream volume control
Redirecting streams
Changing settings on the fly
- sample format
- channel count
Virtual audio devices
- ALSA devices are linked to a real HW device

|||

Why use X over ALSA

ALSA documentation is horrible

Samples/bytes/frames used interchangebly
- Even though they aren't!!!
Incorrect for some features
- Asynchronous mode
  - SND_PCM_ASYNC in snd_pcm_open()
Job protection?

Internals

|||

Main configuration

Default config
- /usr/share/alsa/alsa.conf
- Not meant to be changed
- Normally, just defines default devices without any plugins
System wide specific configuration
- /etc/asoundrc
User specific configuration
- ~/.asoundrc
All config files are parsed every time an ALSA device is opened
- No restart necessary for changes to take effect!

|||

Configuration

Alsa uses *.conf files to configure sound devices

Located in /usr/share/alsa/cards
Organized in a hierarchical fashion
- Cards
  - A physical card or logical kernel device capable of input and/or output
- Devices
  - A card can have several devices
  - Can be operated independently from each other
- Subdevices
  - A sound endpoint for the device
  - F.e. Left and right channel can be separate subdevices

|||

Configuration Pitfalls

Device can have separate subdevice for left or right channel
- Can be controlled separately in principle...
- In practice, writing/reading from a subdevice locks the other subdevices
Application selects audio device using a device string
- Device string is the 'absolute' path of the device
  - card,device[subdevice]
- aplay utility can list all pcm devices
  - aplay -L

|||

Configuration

Each card sets one/multiple interfaces which determine what ALSA API can be used.

pcm
- PCM interface
- snd_pcm_* API
- API used to read/write audio data to a device
ctl
- Control interface
- snd_ctl_* API
  - snd_ctl_get_dB_range, set/get parameters from ALSA driver, ...
- Transfer data in Type/Length/Value(TLV)-way to ALSA driver from userspace
- Fun fact: No limitation on size of data
  - Abused for I/O operations

||| More and more interfaces...

amixer
- Simple mixer interface
- snd_mixer_* API
- Setting volume, ...
amidi
seq
hwdep
rawmidi
...

|||

Configuration

User can hook in ALSA plugins to a device
- Conceptually, an ALSA device is a wrapper for its plugins
- We built our usecase in the config files

|||

PCM Configuration

The 'type' field determines which plugin is loaded for this PCM device.

hw
plug
shm
dmix
dsnoop
asym
softvol
- If sound card does not support volume control by HW
- Add pure SW volume control for a device
...

See https://www.alsa-project.org/alsa-doc/alsa-lib/pcm_plugins.html for a full list.

|||

PCM Configuration

hw type

Direct access to the kernel device
No software mixing or stream adaptation support
Minimal latency
PCM parameter that is not supported by HW?
- Error is returned

|||

PCM Configuration

plug type

"Plug-and-play"
- Performs channel duplication, resampling, ...
PCM parameter that is not supported by HW?
- No error returned
Not something you want if latency is critical

|||

Config file example

What does this say?

# My awesome PCM device
pcm.plug0 {
  type plug
  slave {
    pcm "hw:0,0"
  }
}

|||

Config file example

# My awesome PCM device
pcm.plug0 {
  type plug
  slave {
    pcm "hw:0,0"
  }
}

ALSA PCM device with name 'plug0'

Determines which API we can use to open the device in alsa-lib
In this case : PCM

|||

Config file example

# My awesome PCM device
pcm.plug0 {
  type plug
  slave {
    pcm "hw:0,0"
  }
}

Load the plug plugin

Handles data output to this device
Does automatic sample rate conversion if needed
Plugins need a slave device!

|||

Config file example

# My awesome PCM device
pcm.plug0 {
  type plug
  slave {
    pcm "hw:0,0"
  }
}

This PCM device is for your first sound card (0) and first device (0)

||| ALSA leaves some freedom on how to write the configuration files

pcm_slave.slave0 {
    pcm "hw:0,0"
}

pcm.plug0 {
  type plug
  slave slave0
}

|||

pcm_slave.slave0 {
    pcm "hw:0,0"
    channels 6
    rate 96000
}

pcm.plug0 {
  type plug
  slave slave0
}

Here we restrict the device's hardware parameter space

Play on 6 channels
Set the samplerate to 96kHz

Important: Anything that can be set through the ALSA PCM API can be set in the config file!

|||

ALSA mysteries

My latency is too high

Check which card.conf is being loaded
- strace is your friend and wants to help you... unlike ALSA
Check if some parameters are being set statically
- Period size
- Buffer size
- ...

|||

Some interesting stuff

Exclamation sign causes previous definition to be overridden

pcm.!default { type hw card 0 }

Can also use:

?: assign if not already assigned (so do not override)
+: create new parameter when necessary
- Default behaviour and therefore useless
-: Cause error when trying to assign a parameter which did not previously exist

|||

More interesting stuff

Functions in the configuration

Modify configuration at runtime
- f.e. through env-variable

pcm.!default {
    type plug
    slave.pcm {
        @func getenv
        vars [ ALSAPCM ]
        default "hw:myAwesomeAudioDevice"
    }
}

Good luck with that...

|||

More more interesting stuff

Hook functions to configure device when device is opened

setting volume to 0
...

Good luck with that...

PCM

Digitized sound

Samplerate
Channels
Sample format

Not as easy as just setting them one by one

|||

PCM configuration

Constructs a configuration space
PCM parameters are not independent from each other for some sound cards
- Cannot combine all sample formats with all sampling rates or channel counts

|||

PCM configuration

ALSA constructs an n-dimensional space to limit possible combinations
- Samplerate dimension
- Channel dimension
- Sample format dimension
- ...
Therefore, In ALSA API, we set a minimum samplerate
- snd_pcm_hw_params_set_rate_near(), snd_pcm_hw_params_set_channels_near(), ...
- This narrows down the possible channels, sample format, ...
- So order of configuration is important!
  - Order of parameters determines the parameters selected

|||

PCM configuration

Ok, but how do I know what params are actually set?!

printf
/proc/asound/card#/pcm#/sub#/hw_params
aplay -v

Simple usecase

1 device recording and playing

|||

Several ways to tackle this

Blocking
Non-blocking
Asynchronous
Polling

|||

Blocking

one thread per device
- capture and playback are two separate devices!
Results in two threads

|||

Blocking

#define AUDIO_SAMPLERATE           16000

#define AUDIO_NR_OF_SAMPLES        128u
#define AUDIO_BYTES_PER_SAMPLE     2u
#define AUDIO_OUTPUT_NR_CHANNELS   2u
#define SAMPLE_BUFFER_SIZE         (AUDIO_NR_OF_SAMPLES * AUDIO_OUTPUT_NR_CHANNELS * AUDIO_BYTES_PER_SAMPLE)

int main(int argc, char **argv)
{
    snd_pcm_t *handle = NULL;
    int period_size = 0;
    int period_time = 0;
    char my_samples[SAMPLE_BUFFER_SIZE];

    snd_pcm_open(&handle, "default:CARD=MyAwesomeAudioCard", SND_PCM_STREAM_PLAYBACK, 0);

    snd_pcm_hw_params_t *hw_params;
    snd_pcm_hw_params_alloca(&hw_params);
    snd_pcm_hw_params_current(handle, hw_params);

    snd_pcm_hw_params_set_access(handle, hw_params, SND_MODE_INTERLEAVED);
    snd_pcm_hw_params_set_format(handle, hw_params, SND_PCM_FORMAT_U16);
    snd_pcm_hw_params_set_rate_near(handle, hw_params, AUDIO_SAMPLERATE);

    snd_pcm_hw_params(handle, hw_params);

    snd_pcm_hw_params_get_period_size(params, period_size, 0);
    snd_pcm_hw_params_get_period_time(params, period_time, NULL);


    snd_pcm_sw_params_t *sw_params = NULL;
    snd_pcm_sw_params_malloc(&sw_params);
    snd_pcm_sw_params_current(handle, sw_params); // AFTER hw params!

    snd_pcm_sw_params_set_start_threshold(handle, sw_params, AUDIO_NR_OF_SAMPLES);

    snd_pcm_sw_params(handle, sw_params);

    // DUMP SETTINGS
    snd_output_t *output = NULL;
    snd_output_stdio_attach(&output, stdout, 0);
    snd_pcm_dump(handle, output);

    // Prepare codec for output
    snd_pcm_drop(handle); // Just to be sure...
    snd_pcm_prepare(handle);

    // ALSA gods demand their buffers to be prefilled with 2 period sizes!
    snd_pcm_writei(handle, my_samples, AUDIO_NR_OF_SAMPLES);
    snd_pcm_writei(handle, my_samples, AUDIO_NR_OF_SAMPLES);

    // Codec is started after this
    snd_pcm_state(handle) == SND_PCM_STATE_RUNNING;

    // Do our thing...
    while(1) {
        int error = snd_pcm_writei(handle, my_samples, AUDIO_NR_OF_SAMPLES);
        if (error < 0) {
            // xrun recovery
			int recover = snd_pcm_recover(handle, error, 1);
			if (recover < 0) {
			    // all hope is lost....
			}
			// After recovery, need to prefill codec again!
            snd_pcm_writei(handle, my_samples, AUDIO_NR_OF_SAMPLES);
            snd_pcm_writei(handle, my_samples, AUDIO_NR_OF_SAMPLES);
        }
    }
}

|||

Non-Blocking

Same as blocking
Functions return new error codes
- -EBUSY when resource is unavailable
  - aka you did something fishy...
- -EAGAIN if buffers are full

|||

Non-Blocking

#define AUDIO_SAMPLERATE           16000

#define AUDIO_NR_OF_SAMPLES        128u
#define AUDIO_BYTES_PER_SAMPLE     2u
#define AUDIO_OUTPUT_NR_CHANNELS   2u
#define SAMPLE_BUFFER_SIZE         (AUDIO_NR_OF_SAMPLES * AUDIO_OUTPUT_NR_CHANNELS * AUDIO_BYTES_PER_SAMPLE)

int main(int argc, char **argv)
{
    snd_pcm_t *handle = NULL;
    int period_size = 0;
    int period_time = 0;
    char my_samples[SAMPLE_BUFFER_SIZE];

    // Open PCM in non-blocking
    snd_pcm_open(&handle, "default:CARD=MyAwesomeAudioCard", SND_PCM_STREAM_PLAYBACK, SND_PCM_NONBLOCK);

    // setup rest of stuff...

    // Prepare codec for output
    snd_pcm_drop(handle); // Just to be sure...
    snd_pcm_prepare(handle);

    // ALSA gods demand their buffers to be prefilled with 2 period sizes!
	snd_pcm_non_block(handle, 0); // We want to block for the prefill
    snd_pcm_writei(handle, my_samples, AUDIO_NR_OF_SAMPLES);
    snd_pcm_writei(handle, my_samples, AUDIO_NR_OF_SAMPLES);
	snd_pcm_non_block(handle, 1); // get back to non-blocking

    // Codec is started after this
    snd_pcm_state(handle) == SND_PCM_STATE_RUNNING;

    // Do our thing...
    while(1) {
        int error = snd_pcm_writei(handle, my_samples, AUDIO_NR_OF_SAMPLES);
		if (error == -EAGAIN) {
		    sleep(100);
			continue;
		}
		// xrun recovery stuff
    }
}

|||

Async

'Microcontroller'-way (patent pending)
Seems natural/elegant
- Why let us do the waiting when ALSA can just inform us when it wants samples?
Uses SIGIO by default
- Wizards can redefine it to a realtime signal (actual quote from ALSA docs...)
ALSA Driver has to raise the signal
- So it's not supported by a lot of drivers
- Can conflict with other modules/libraries/... using the same signal
  - Hence, you have to be a wizard to get it working

|||

Async

Not very stable...
- Seems confirmed by the fact that nobody seems to use it
- Big players (PulseAudio/JACK/PortAudio) don't use it
My official recommendation: don't use it if you want to maintain your sanity...

|||

Async

#define AUDIO_SAMPLERATE           16000

#define AUDIO_NR_OF_SAMPLES        128u
#define AUDIO_BYTES_PER_SAMPLE     2u
#define AUDIO_OUTPUT_NR_CHANNELS   2u
#define SAMPLE_BUFFER_SIZE         (AUDIO_NR_OF_SAMPLES * AUDIO_OUTPUT_NR_CHANNELS * AUDIO_BYTES_PER_SAMPLE)

static void my_signal_callback(snd_async_handler_t *ahandler)
{
    snd_pcm_t *pcm_handle = snd_async_handler_get_pcm(ahandler);
    void *my_priv_data = snd_async_hanlder_get_callback_private(ahandler);
    char my_samples[SAMPLE_BUFFER_SIZE] = { 0 };

    snd_pcm_sframes_t avail = 0;

    avail = snd_pcm_avail_update(pcm_handle);

    if (avail < 0) {
        // xrun recovery
    }

    while (avail >= AUDIO_NR_SAMPLES) {
        snd_pcm_writei(pcm_handle, my_samples, AUDIO_NR_SAMPLES);
        avail = snd_pcm_avail_update(pcm_handle);
		// xrun checking...
    }
}

int main(int argc, char **argv)
{
    snd_pcm_t *handle = NULL;
    snd_async_handler_t *async_handle = NULL;
    void *my_priv_data = NULL;
    int period_size = 0;
    int period_time = 0;
    char my_samples[SAMPLE_BUFFER_SIZE];

    // Open pcm, non-blocking or blocking, your choice
    snd_pcm_open(&handle, "default:CARD=MyAwesomeAudioCard", SND_PCM_STREAM_PLAYBACK, 0);
    // Just... for the love of god.... don't use SND_PCM_ASYNC!!!
    // snd_pcm_open(&handle, "default:CARD=MyAwesomeAudioCard", SND_PCM_STREAM_PLAYBACK, SND_PCM_ASYNC);

    // setup rest of stuff...

    // Install callback
    snd_pcm_add_pcm_handler(&async_handle, handle, my_signal_callback, my_priv_data);

    // Prepare codec for output
    snd_pcm_drop(handle); // Just to be sure...
    snd_pcm_prepare(handle);

    // ALSA gods demand their buffers to be prefilled with 2 period sizes!
    snd_pcm_writei(handle, my_samples, AUDIO_NR_OF_SAMPLES);
    snd_pcm_writei(handle, my_samples, AUDIO_NR_OF_SAMPLES);

    // Codec is started after this
    snd_pcm_state(handle) == SND_PCM_STATE_RUNNING;

    while(1) {
        // everything is handled in callback
        sleep(100);
    }
}

|||

Polling

Closest to the async model and still managable/stable
We ask ALSA for file descriptors of the audio device we can poll
- Depending on Playback/Recording, poll returns POLLOUT/POLLIN
Sweet!
No need for sleeps, waiting, ....

|||

Polling

Oh you naive fool....

ALSA can generate 'NULL' events
- Yes, stated by their official documentation...
So your thread is always waking up and checking for null events
You still have to throttle the thread/poll yourself....

|||

Polling

int main(int argc, char **argv)
{
//TODO
}

|||

ALSA quirks

alsa-lib startup behaviour for output devices
- Need to be prefilled with 2 * period_size
- Just because
- If not... xrun after a while...without them being reported in your app
  - Errors in dmesg
Maintain handshake with library
- Get state from pcm handle
- Depending on that state, do stuff
  - recover from xrun
  - prepare again after xrun
  - prefill before writing your own audio!
- https://www.alsa-project.org/alsa-doc/alsa-lib/pcm.html
Input/output settings linked to each other on same device
- Sounds logical...
- ...However, ALSA will allow to let you define f.e. 48kHz on input and 16kHz on output
- Even though this isn't possible due to HW constraints (it's the same device!)

Complex usecase

Several devices

|||

Blocking

Extrapolate the blocking usecase

1 device == 1 thread
Simple
But resource heavy....
- f.e. 8 Audio devices, full duplex (playback and recording)
- 8 devices x 2 threads = 16!

|||

Blocking

int main(int argc, char **argv)
{
//TODO
}

|||

Polling

Bookkeeping
- Figuring out which device generated event
One device can influence others
- If one device takes too long writing/reading, the others can experience xrun
But, this seems to be the only stable/flexible way to handle multiple alsa devices in a performance/resource-friendly way.

|||

Polling

int main(int argc, char **argv)
{
//TODO
}

Tips and tricks

Thread safety
- Opening audio devices is thread safe and returns a handle
- User is responsible for serializing acces to handle-related functions
  - So you have to provide your own locking scheme if handle is shared!
- Standalone (non-handle) functions are thread safe though
Disable multi-thread support at runtime
- LIBASOUND_THREAD_SAFE=0
Check the official examples
- The API doesn't work as you would think it works
Check alsa-utils

|||

Tips and tricks

Check alsa-mixer for volume control implementation
- Human ear is an a-hole
Check PortAudio/PulseAudio/JACK/...
- Not just for 'code ideas'
- You can use them iso ALSA
  - But check performance impact
Useful tools
- aplay
  - list all devices: aplay -l
  - list configuration of device: aplay -v
Some functions are notorious for not being stable
- snd_pcm_drain
  - Comment in PortAudio:src/hostapi/alsa/pa_linux_alsa.c:AlsaStop: "snd_pcm_drain can hang forever."
  - Commit from 2013...

|||

Tips and tricks

ALSA output devices startup behaviour
- Need to be prefilled with 2 * period_size
- Just because
- If not... xrun after a while
Configured audio devices
- /proc/asound/cards
State of sound devices stored persistently
- Alsa-utils
- /var/lib/alsa/asound.state
- Can be disabled

|||

Future stuff

ALSA/alsa-lib introduced usecase managers

Headset
Speakers
Microphone
...

Used in Ubuntu Touch (Nexus 7)

Ability to set actions
- EnableSpeakers
- DisableMicrophone

Sources

Wiki https://alsa-project.org/wiki
- Contains a lot of dead links
- Mostly replaced with kernel info (see below)
Unofficial wiki https://alsa.opensrc.org/
- Is more honest about stuff that is broken etc.
Kernel info https://www.kernel.org/doc/html/v4.17/sound/index.html
- Writing an ALSA driver https://www.kernel.org/doc/html/v4.17/sound/kernel-api/writing-an-alsa-driver.html

|||

Sources

Some guy that also struggled http://www.volkerschatz.com/noise/alsa.html
Sample programs http://equalarea.com/paul/alsa-audio.html
alsa-lib doxygen https://www.alsa-project.org/alsa-doc/alsa-lib/
- Handshake between app and lib https://www.alsa-project.org/alsa-doc/alsa-lib/pcm.html
Arch is the best wiki ever https://wiki.archlinux.org/index.php/Advanced_Linux_Sound_Architecture
Recent ALSA examples https://github.com/OpenPixelSystems/c-alsa-examples

21 KiB Raw Blame History

ALSA

What?

What?

What?

History

Who uses it?

Why?

Why you should use ALSA over OSS

Why you should use ALSA over a sound server

Why you should use a sound server over ALSA

Why use X over ALSA

Internals

Main configuration

Configuration

Configuration Pitfalls

Configuration

Configuration

PCM Configuration

PCM Configuration

hw type

PCM Configuration

plug type

Config file example

Config file example

Config file example

Config file example

ALSA mysteries

My latency is too high

Some interesting stuff

More interesting stuff

More more interesting stuff

PCM

PCM configuration

PCM configuration

PCM configuration

Simple usecase

Several ways to tackle this

Blocking

Blocking

Non-Blocking

Non-Blocking

Async

Async

Async

Polling

Polling

Polling

ALSA quirks

Complex usecase

Blocking

Blocking

Polling

Polling

Tips and tricks

Tips and tricks

Tips and tricks

Future stuff

Sources

Sources

21 KiB

Raw Blame History
